PRV Audio EX4.6 PRO 4-Way Crossover

Name: PRV Audio EX4.6 PRO 4-Way Crossover
Brand: PRV Audio
Price: 69.91 USD
Availability: InStock

No reviews

Price:

$69.91

Stock:

In stock

Quantity:

{"id":7724586828034,"title":"PRV Audio EX4.6 PRO 4-Way Crossover","handle":"ex4-6-pro","description":"\u003ch1\u003e\u003cstrong\u003eDescription\u003c\/strong\u003e\u003c\/h1\u003e\n\u003cp\u003eBringing innovation and technology to the automotive sound market, PRV Audio launches the EX4.6 PRO electronic crossover, giving you the power to customize your sound with a wide frequency of filter adjustments. Featuring 4-way adjustable HIGH PASS and LOW PASS filters and also output level control on each channel, plus adjustable BASS-BOOST option on the Sub Out channel. Enhancing Your Audio System!\u003c\/p\u003e\n\u003ch4\u003e\u003cstrong\u003eHighlights\u003c\/strong\u003e\u003c\/h4\u003e\n\u003cul\u003e\n\u003cli\u003e2\/3\/4 RCA Input Signal Options\u003c\/li\u003e\n\u003cli\u003e9 Volts RMS maximum output\u003c\/li\u003e\n\u003cli\u003eBass Boost 0 to 12dB set at 45Hz\u003c\/li\u003e\n\u003cli\u003eQuick On\/Off button for each channel\u003c\/li\u003e\n\u003cli\u003eCrossover slope rate: Butterworth 12 db\/Octave\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cp\u003e\u003cstrong\u003eInput and output Functions:\u003c\/strong\u003e\u003cbr\u003e– 2\/3\/4 RCA inputs for 3 Channels – 1 Stereo and 2 Mono\u003cbr\u003e– 6 RCA outputs for 4 Channels – 2 Stereo and 2 Mono\u003c\/p\u003e\n\u003ch4\u003eGENERAL SPECIFICATIONS\u003c\/h4\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cdiv class=\"wp-container-1 wp-block-column\"\u003e\n\u003ctable class=\"wp-block-table is-style-stripes\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eHigh Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 400Hz – 10KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMid High Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 150Hz – 5KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMid Low Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 25Hz – 3KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSub Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eLow Pass – 50Hz – 250KHz (12dB\/8a) Bass Boost – 25Hz – 110Hz (0 – +12dB; 45Hz)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMaximum Output Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e9V RMS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMaximum Input Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e4V RMS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSignal to Noise\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e\u0026gt;90dB\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eInput Impedance\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e10K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eHarmonic Distortion\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u0026lt; 0.02% THD\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eChannel Separation\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u0026gt; 80dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eFrequency Response\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e20Hz-200KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSupply Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e10V – 16V DC\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eCurrent Consumption\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e200mA\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eImpedance Output\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e470 Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eDimensions (H x W x L)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e1.30″ x 9″ x 6.30″\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eWeight\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e1.45 Lbs\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e","published_at":"2022-07-06T04:18:56-05:00","created_at":"2022-06-24T10:30:17-05:00","vendor":"PRV Audio","type":"","tags":["Crossover"],"price":6991,"price_min":6991,"price_max":6991,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42928387162370,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"PRV Audio EX4.6 PRO 4-Way Crossover","public_title":null,"options":["Default Title"],"price":6991,"weight":658,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Angle-View.jpg?v=1656084619","\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-inputs-View.jpg?v=1656084619","\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Top-View.jpg?v=1656084619"],"featured_image":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Angle-View.jpg?v=1656084619","options":["Title"],"media":[{"alt":null,"id":30071067083010,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Angle-View.jpg?v=1656084619"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Angle-View.jpg?v=1656084619","width":800},{"alt":null,"id":30071067115778,"position":2,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-inputs-View.jpg?v=1656084619"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-inputs-View.jpg?v=1656084619","width":800},{"alt":null,"id":30071067148546,"position":3,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Top-View.jpg?v=1656084619"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/www.mooncarstereo.com\/cdn\/shop\/products\/EX4-6-Pro-Top-View.jpg?v=1656084619","width":800}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch1\u003e\u003cstrong\u003eDescription\u003c\/strong\u003e\u003c\/h1\u003e\n\u003cp\u003eBringing innovation and technology to the automotive sound market, PRV Audio launches the EX4.6 PRO electronic crossover, giving you the power to customize your sound with a wide frequency of filter adjustments. Featuring 4-way adjustable HIGH PASS and LOW PASS filters and also output level control on each channel, plus adjustable BASS-BOOST option on the Sub Out channel. Enhancing Your Audio System!\u003c\/p\u003e\n\u003ch4\u003e\u003cstrong\u003eHighlights\u003c\/strong\u003e\u003c\/h4\u003e\n\u003cul\u003e\n\u003cli\u003e2\/3\/4 RCA Input Signal Options\u003c\/li\u003e\n\u003cli\u003e9 Volts RMS maximum output\u003c\/li\u003e\n\u003cli\u003eBass Boost 0 to 12dB set at 45Hz\u003c\/li\u003e\n\u003cli\u003eQuick On\/Off button for each channel\u003c\/li\u003e\n\u003cli\u003eCrossover slope rate: Butterworth 12 db\/Octave\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cp\u003e\u003cstrong\u003eInput and output Functions:\u003c\/strong\u003e\u003cbr\u003e– 2\/3\/4 RCA inputs for 3 Channels – 1 Stereo and 2 Mono\u003cbr\u003e– 6 RCA outputs for 4 Channels – 2 Stereo and 2 Mono\u003c\/p\u003e\n\u003ch4\u003eGENERAL SPECIFICATIONS\u003c\/h4\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cdiv class=\"wp-container-1 wp-block-column\"\u003e\n\u003ctable class=\"wp-block-table is-style-stripes\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eHigh Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 400Hz – 10KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMid High Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 150Hz – 5KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMid Low Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eHigh Pass – 25Hz – 3KHz (12dB\/8a)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSub Out Channel\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eLow Pass – 50Hz – 250KHz (12dB\/8a) Bass Boost – 25Hz – 110Hz (0 – +12dB; 45Hz)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMaximum Output Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e9V RMS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eMaximum Input Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e4V RMS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSignal to Noise\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003e\u0026gt;90dB\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eInput Impedance\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e10K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eHarmonic Distortion\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u0026lt; 0.02% THD\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eChannel Separation\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u0026gt; 80dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eFrequency Response\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e20Hz-200KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSupply Voltage\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e10V – 16V DC\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eCurrent Consumption\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e200mA\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eImpedance Output\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e470 Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eDimensions (H x W x L)\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e1.30″ x 9″ x 6.30″\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eWeight\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e1.45 Lbs\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e"}

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Share this product

Description

Bringing innovation and technology to the automotive sound market, PRV Audio launches the EX4.6 PRO electronic crossover, giving you the power to customize your sound with a wide frequency of filter adjustments. Featuring 4-way adjustable HIGH PASS and LOW PASS filters and also output level control on each channel, plus adjustable BASS-BOOST option on the Sub Out channel. Enhancing Your Audio System!

Highlights

2/3/4 RCA Input Signal Options
9 Volts RMS maximum output
Bass Boost 0 to 12dB set at 45Hz
Quick On/Off button for each channel
Crossover slope rate: Butterworth 12 db/Octave

Input and output Functions:
– 2/3/4 RCA inputs for 3 Channels – 1 Stereo and 2 Mono
– 6 RCA outputs for 4 Channels – 2 Stereo and 2 Mono

GENERAL SPECIFICATIONS

High Out Channel	High Pass – 400Hz – 10KHz (12dB/8a)
Mid High Out Channel	High Pass – 150Hz – 5KHz (12dB/8a)
Mid Low Out Channel	High Pass – 25Hz – 3KHz (12dB/8a)
Sub Out Channel	Low Pass – 50Hz – 250KHz (12dB/8a) Bass Boost – 25Hz – 110Hz (0 – +12dB; 45Hz)
Maximum Output Voltage	9V RMS
Maximum Input Voltage	4V RMS
Signal to Noise	>90dB
Input Impedance	10K Ohms
Harmonic Distortion	< 0.02% THD
Channel Separation	> 80dB
Frequency Response	20Hz-200KHz
Supply Voltage	10V – 16V DC
Current Consumption	200mA
Impedance Output	470 Ohms
Dimensions (H x W x L)	1.30″ x 9″ x 6.30″
Weight	1.45 Lbs

PRV Audio EX4.6 PRO 4-Way Crossover
